Valpadana, the rich range of specialized tractors

by Giovanni M. Losavio
October - November 2016 | Back

From the super compact series VP 4600 and VP 7000 up to the professional VP 9000, Valpadana takes centre stage at EIMA 2016 with a full range of models. The range of Valpadana tractors is designed to meet all the needs of intensive crops such as vineyards and orchards, crops in greenhouses or nurseries, and those related to public and private landscaping. The VP 4600 Series consists of three models with three and four-cylinder Yanmar 23 Hp engines with indirect injection, and 35.4 Hp and 47.3 Hp with direct injection.

Available in both “structured” and “variant” configurations, both one-way, the VP 4600 series is characterized by a powerful oil-bath multi-disc braking system, by a transmission with 8 FWD + 4 REV synchronized reverser and fully independent PTO with dedicated multi-clutch. The standard equipment includes a lift with lowering speed regulator and a maximum lifting capacity of 1,000 kg. The 7070 and 7080 models that make up the VP7000 series, ideal for agriculture professionals, have powers of 65 Hp and 75 Hp. The range is equipped with 3,200 cc 4-cylinder turbo Stage IIIA FPT engines. The hallmark of the VP7000 series is the 16 FWD + 16 REV transmission with mechanical reverser and creeper as standard (from 0.8 to 40 km/h) produced 100% by Argo Tractors. The front axle features 4WD attachments and electro-hydraulic differential locks. The VP9000 Series is in the highest range of Valpadana equal-wheeled tractors. The 9095 and 90105 models are rated respectively at 88 HP and 95 Hp. The transmission, produced by Argo Tractors, applies to all 16FWD + 16REV models and is equipped with a synchronized mechanical reverser with a De-Clutch button to activate the reversal without pressing the clutch pedal. The rear lift has a lifting capacity of 2,300 kg, and the double pump hydraulic system with a total flow rate of 81 l/min is available on request with four distributors, managed electronically with a proportional joystick control lever. All models are available in a platform version and with a cabin with reversible driving position. The cabin stands out for its excellent habitability, equipped with a monocoque frame and air-suspension seat.
